ORP Analyzer
Our ORP sensors and transmitters are used in many industries. Such as: chemical, water & wastewater, power, pharmaceuticals and pulp & paper. The selection of the sensor depends on the application.
Transmitter Selection
Electrode Selection
|
Model |
Sewage electrode: ORP01 |
Glass electrode: ORP02 |
PTFE electrode: ORP03 |
Digital electrode: ORP485 |
|
Measurement range: |
±1999mV |
|||
|
Temperature |
0-60℃ |
|||
|
Temperature compensation |
NTC2252, NTC10K, PT1000, PT100 |
____ |
||
|
Power supply |
------- |
12-24VDC |
||
|
Output |
RS485 |
|||
|
Liquid Contact material |
PPS, quartz glass, PTFE |
quartz glass |
quartz glass, PTFE |
PPS, quartz glass, PTFE |
|
Installation interface |
NPT3/4 |
PG13.5mm |
NPT3/4 |
NPT3/4 |
|
Electrode withstand voltage |
0.3Mpa, 0.6Mpa |
|||
|
Application |
industrial sewage treatment |
mining and smelting, papermaking, petrochemical, biotechnology and other fields |
industrial wastewater, acid-base neutralization, strong acid and strong alkali conditions, Heavily polluted water quality |
water treatment, surface water, etc. |
