It suitable for Ammonia nitrogen, nitrate nitrogen, F-,Cl-,Ca2+, Na+, K+ Cu2+, Lead ions, cyanide ions, cadmium ions
The ion instrument is widely used for power plant, drinking water, industrial waste water etc.
Transmitter Selection
Electrode Selection
|
Model |
LZ485-XX |
|
Principle |
ion electrode method |
|
Measurement range |
Ammonia nitrogen 0-1000mg/L, Nitrogen: 0-1000mg/L, Fluoride ion: 0-100mg/L, Calcium ion: 0-1000mg/L, Chloride ion: 0-1000mg/L, Sodium ion 0-100mg/L, Potassium ion 0-1000mg/L, Lead ion 0-1000mg/L, Copper ion 0-100mg/L, fluoride ion 0-200mg/L, cadmium ion 0-1000mg/L |
|
Temperature |
0-50℃ |
|
Water depth: |
10mMax, IP68 |
|
Power supply |
12-24VDC |
|
Output |
RS485 |
|
Material |
ABS |
|
Installation |
NPT3/4 |
|
Size |
length: 250mm, diameter: 37mm, weight: 0.5kg |
|
Response time |
T90, <30s |
