Turbidity Analyzer
is mainly used in the safeguarding of water quality in many fields of production, it’s washing water, filter loads, goods income control or development. Depending on the application various light sources and technologies may be used. Field applications range from the pharmaceutical industry, chemical industry, fuel industry and motor development to the monitoring of the food and beverage industry.
Transmitter Selection
Electrode Selection
|
Model |
NTU100 |
NTU200 |
self-cleaning Model: NTU300 |
high temperature type Model: NTU2000-500 |
|
principle |
infrared optical method |
infrared optical method |
infrared optical method |
infrared optical method |
|
Measurement range |
0-10NTU, 0-200NTU, 0-4000NTU, Support OEM |
0-10NTU, 0-200NTU, 0-4000NTU Support OEM |
0-100NTU, 0-400NTU, 0-4000NTU Support OEM |
0-100NTU, 0-2400NTU, 0-4000NTU Support OEM |
|
Resolution |
0.01NTU, 0.1NTU, 1NTU |
|||
|
Temperature |
-10-50℃ |
-10-50℃ |
-10-50℃ |
0-180℃ |
|
Water depth |
10mMax, IP68 |
|
10mMax, IP68 |
|
|
Cleaning method |
______ |
______ |
automatic scraper |
______ |
|
Power supply |
12-24VDC |
12-24VDC |
12-24VDC |
12-24VDC |
|
Output |
4-20mA, RS485 |
4-20mA, RS485 |
4-20mA, RS485 |
4-20mA, RS485 |
|
installation |
NPT3/4 immersion |
Flow cup, |
NPT3/4 |
Flow cup/immersion (customized) |
|
Material |
304, POM, quartz glass |
304, POM, quartz glass, acrylic |
304, POM, quartz glass |
304, PTFE, quartz glass |
|
Response time |
T90, <30s |
|||
|
Application |
sewage, surface water, tap water, swimming pool, etc. |
sewage, surface water, tap water, swimming pool, etc. |
sewage, surface water, swimming pools, aquaculture, sewage pipe networks, etc. |
chemical industry, sewage, beer process, etc. |
